NTN Tonlager Zelfinstellend 23124 Cilindrisch EAW33 C3 (120x200x62mm)
Product information
If you have any questions about the NTN Tonlager Zelfinstellend 23124 Cilindrisch EAW33 C3 (120x200x62mm), don't hesitate to contact us.
For ordering greater numbers don't hesitate to send us a quotation request.
Share this product on social media!
- Free shipping within The Netherlands
- Easy return
Technical data
Artikelposition
BO202436
NTN, Tonlager, Zelfinstellend, 23124, Cilindrisch, EAW33, C3, 120x200x62mm.
O.E.M. Nummer
Nein
Brand
NTN
Typ
Nein
Seal
No seal
Tolerance Class
C0 (Standard)
Asdiameter - d (mm)
120
Buitendiameter - D (mm)
200
Dikte - B (mm)
62
r min (mm)
2
Vetsoort
Nicht zutreffend
Kooi
Nicht zutreffend
Boring
Nicht zutreffend
Statisch Draaggetal (N)
820000
Dynamisch Draaggetal (N)
663000
Grenstoerental (tr/min)
3200
Referentietoerental (tr/min)
2600
Gewicht
7.7600
EAN
3413521059025
