NSK Kogellager 6238 M C3 (190x340x55mm)
Product information
This product is made from Staal.
If you have any questions about the NSK Kogellager 6238 M C3 (190x340x55mm), don't hesitate to contact us.
For ordering greater numbers don't hesitate to send us a quotation request.
Share this product on social media!
- Free shipping within The Netherlands
- Easy return
Technical data
Artikelposition
BO628433
O.E.M. Nummer
Nein
Zonder, afdichting, NSK, Kogellager, 6238, C3, 190x340x55mm.
Brand
NSK
Typ
6238
Seal
No seal
Material
Staal
Materiaal Type
Nicht zutreffend
Buitenring
Zonder flens/groef
Kooi
Messing
Boring
Cilindrisch
Details
Nein
Tolerance Class
C3
Asdiameter (mm)
190
Buitendiameter (mm)
340
Dikte (mm)
55
Vetsoort
Nicht zutreffend
Temperatuurbereik
-20° tot +150°C
Statisch Draaggetal (N)
282000
Dynamisch Draaggetal (N)
280000
Grenstoerental (tr/min)
1600
Referentietoerental (tr/min)
Nein
EAN
Nein
HS Code
8482 1090
Gewicht
22.8000
