IBB Kogellager 1603 ZZ (7.94x22.23x7.14mm)
Product information
This product is made from Staal.
If you have any questions about the IBB Kogellager 1603 ZZ (7.94x22.23x7.14mm), don't hesitate to contact us.
For ordering greater numbers don't hesitate to send us a quotation request.
Share this product on social media!
- Easy return
Technical data
Artikelposition
BO118576
O.E.M. Nummer
Nein
ZZ, kanten, stalen, afdichting, IBB, Kogellager, 1603, 7.94x22.23x7.14mm.
Brand
IBB
Typ
1603
Seal
ZZ (2 sides metal shield)
Material
Staal
Materiaal Type
Nicht zutreffend
Buitenring
Zonder flens/groef
Kooi
Nicht zutreffend
Boring
Nicht zutreffend
Details
Nein
Tolerance Class
C0 (Standard)
Asdiameter (mm)
7.94
Buitendiameter (mm)
22.23
Dikte (mm)
7.14
Vetsoort
Nicht zutreffend
Temperatuurbereik
Nicht zutreffend
Statisch Draaggetal (N)
1011
Dynamisch Draaggetal (N)
2065
Grenstoerental (tr/min)
Nein
Referentietoerental (tr/min)
Nein
EAN
Nein
Gewicht
0.0120
