IBB Hoekcontactlager Tweerijig 5209/3209 B 2RS (45x85x30.2mm)
Product information
If you have any questions about the IBB Hoekcontactlager Tweerijig 5209/3209 B 2RS (45x85x30.2mm), don't hesitate to contact us.
For ordering greater numbers don't hesitate to send us a quotation request.
Share this product on social media!
- Easy return
Technical data
Artikelposition
BO482401
IBB, Hoekcontactlager, Tweerijig, 5209, 3209, 2RS, 45x85x30.2mm.
O.E.M. Nummer
Nein
Brand
IBB
Typ
5209/3209
Seal
2RS (2 sides rubber seal)
Buitenring
Nicht zutreffend
Kooi
Nicht zutreffend
Asdiameter - d (mm)
45
Buitendiameter - D (mm)
85
Dikte - B (mm)
30.2
r min (mm)
1.1
Statisch Draaggetal (N)
35400
Dynamisch Draaggetal (N)
47500
Grenstoerental (tr/min)
Nein
Referentietoerental (tr/min)
Nein
Temperatuurbereik
Nicht zutreffend
Vetsoort
Nicht zutreffend
Tolerance Class
C0 (Standard)
Gewicht
0.7090
EAN
Nein
