IBB Angular Contact Ball Bearing Single Row 7304B (20x85x15mm)
Product information
If you have any questions about the IBB Angular Contact Ball Bearing Single Row 7304B (20x85x15mm), don't hesitate to contact us.
For ordering greater numbers don't hesitate to send us a quotation request.
Share this product on social media!
- Easy return
Technical data
Artikelposition
BO541815
IBB, Angular, Contact, Ball, Bearing, Single, Row, 7304B, 20x85x15mm.
O.E.M. Nummer
Nein
Brand
IBB
Typ
7304B
Seal
No seal
Material
Nicht zutreffend
Kooi
Nicht zutreffend
Buitenring
Nicht zutreffend
Tolerance Class
C0 (Standard)
Temperatuurbereik
Nicht zutreffend
Asdiameter - d (mm)
20
Buitendiameter - D (mm)
52
Dikte - B (mm)
15
r min (mm)
1.1
r1 min (mm)
0.6
Statisch Draaggetal (N)
9900
Dynamisch Draaggetal (N)
19300
Grenstoerental (tr/min)
Nicht zutreffend
Referentietoerental (tr/min)
Nicht zutreffend
Gewicht
0.1500
EAN
Nein
