FAG Tonlager Zelfinstellend 23224 Conisch E1 K TVPB (120x215x76mm)
Product information
If you have any questions about the FAG Tonlager Zelfinstellend 23224 Conisch E1 K TVPB (120x215x76mm), don't hesitate to contact us.
For ordering greater numbers don't hesitate to send us a quotation request.
Share this product on social media!
- Free shipping within The Netherlands
- Easy return
Technical data
Artikelposition
BO995643
FAG, Tonlager, Zelfinstellend, 23224, Conisch, E1, TVPB, 120x215x76mm.
O.E.M. Nummer
Nein
Brand
Fag
Typ
23224
Seal
No seal
Tolerance Class
C0 (Standard)
Asdiameter - d (mm)
120
Buitendiameter - D (mm)
215
Dikte - B (mm)
76
r min (mm)
2.1
Vetsoort
Nicht zutreffend
Kooi
Nicht zutreffend
Boring
Nicht zutreffend
Statisch Draaggetal (N)
1020000
Dynamisch Draaggetal (N)
820000
Grenstoerental (tr/min)
3000
Referentietoerental (tr/min)
1910
Gewicht
11.4000
EAN
4026677830012
