FAG Miniatuur Kogellager 609 2RSR C3 (9x24x7mm)
Product information
This product is made from Staal.
If you have any questions about the FAG Miniatuur Kogellager 609 2RSR C3 (9x24x7mm), don't hesitate to contact us.
For ordering greater numbers don't hesitate to send us a quotation request.
Share this product on social media!
This product is currently out of stock.
- Easy return
Technical data
Artikelposition
BO921557
O.E.M. Nummer
Nein
2RS, kanten, kunststof, afdichting, FAG, Miniatuur, Kogellager, 609, 2RSR, C3, 9x24x7mm.
Brand
Fag
Typ
609
Seal
2RS (2 sides rubber seal)
Material
Staal
Materiaal Type
Nicht zutreffend
Buitenring
Zonder flens/groef
Kooi
Plaatstaal
Boring
Cilindrisch
Details
Nein
Tolerance Class
C3
Asdiameter (mm)
9
Buitendiameter (mm)
24
Dikte (mm)
7
Vetsoort
Nicht zutreffend
Temperatuurbereik
-30º tot +100º C
Statisch Draaggetal (N)
1410
Dynamisch Draaggetal (N)
3350
Grenstoerental (tr/min)
20300
Referentietoerental (tr/min)
28500
EAN
4012802324433
Gewicht
0.0140
