FAG Hoekcontactlager Tweerijig 3202 BD TVH (15x35x15.9mm)
Product information
If you have any questions about the FAG Hoekcontactlager Tweerijig 3202 BD TVH (15x35x15.9mm), don't hesitate to contact us.
For ordering greater numbers don't hesitate to send us a quotation request.
Share this product on social media!
- Easy return
Technical data
Artikelposition
BO252005
FAG, Hoekcontactlager, Tweerijig, 3202, BD, TVH, 15x35x15.9mm.
O.E.M. Nummer
Nein
Brand
Fag
Typ
3202
Seal
Nein
Buitenring
Nicht zutreffend
Kooi
Nicht zutreffend
Asdiameter - d (mm)
15
Buitendiameter - D (mm)
35
Dikte - B (mm)
15.9
r min (mm)
0.6
Statisch Draaggetal (N)
7400
Dynamisch Draaggetal (N)
12600
Grenstoerental (tr/min)
22300
Referentietoerental (tr/min)
18500
Temperatuurbereik
-30º tot +120º C
Vetsoort
Nicht zutreffend
Tolerance Class
Nein
Gewicht
0.0660
EAN
4012802481310
