FAG Hoekcontactlager Eenrijig 7338 B MP UA (190x400x78mm)
Product information
If you have any questions about the FAG Hoekcontactlager Eenrijig 7338 B MP UA (190x400x78mm), don't hesitate to contact us.
For ordering greater numbers don't hesitate to send us a quotation request.
Share this product on social media!
- Free shipping within The Netherlands
- Easy return
Technical data
Artikelposition
BO925687
FAG, Hoekcontactlager, Eenrijig, 7338, MP, UA, 190x400x78mm.
O.E.M. Nummer
Nein
Brand
Fag
Typ
7338
Seal
No seal
Material
Nicht zutreffend
Kooi
Nicht zutreffend
Buitenring
Nicht zutreffend
Tolerance Class
C0 (Standard)
Temperatuurbereik
-30º tot +200º C
Asdiameter - d (mm)
190
Buitendiameter - D (mm)
400
Dikte - B (mm)
78
r min (mm)
5
r1 min (mm)
Nein
Statisch Draaggetal (N)
630000
Dynamisch Draaggetal (N)
440000
Grenstoerental (tr/min)
2490
Referentietoerental (tr/min)
1680
Gewicht
55.0000
EAN
4012801573214
